Browse Bridge Railings

Click on a column heading to arrange the list in the order of that bridge railing characteristic.

Name/Designator Image Material Test Specification Test Level Mounting Type Aesthetic See Through Retrofit Combo Veh./Ped. Review Status
SBA01a
Chicago Barrier Railing
No image. Aluminum (A)    Unknown  No No No No
SBA02a
BR2 Type A Aluminum Bridge Railing
No image. Aluminum (A)    Unknown  No No No No
SBA02b
Foothill Parkway Bridge Railing
No Image Aluminum (A)  AASHTO Guide Spec for Bridge Railings  2 Parapet  Yes Yes No No In Review
SBA03a
BR1 Type C Aluminum Bridge Railing
No image. Aluminum (A)    Unknown  No No No No
SBA03b
NC 1-Bar
No Image Aluminum (A)  AASHTO Guide Spec for Bridge Railings  2 Parapet  Yes Yes No No In Review
SBA04a
Tru-Beam Bridge Railing
No image. Aluminum (A)    Unknown  No No No No
SBA04b
Aluminum True Beam
No image. Aluminum (A)  AASHTO Guide Spec for Bridge Railings  2 Deck  No Yes No No In Review
SBA05d
Truss-Core F-Shape
No Image Aluminum (A)  Report 350  4 Deck  No No No No In Review
SBA07d
EdgeRail
No Image Aluminum (A)  Report 350  4 Curb/Sidewalk  Yes Yes No No Review Complete
SBB01a
2-Tube Curb-Mounted Bridge Railing
No image. Steel Tube (B)    Unknown  No No No No
SBB01b
OregonTwo-Tube Curb-Mounted
No Image Steel Tube (B)  AASHTO Guide Spec for Bridge Railings  2 Curb/Sidewalk  No Yes No No In Review
SBB02a
W and Tube Beam Bridge Railing
No image. Steel Tube (B)    Unknown  No No No No
SBB02b
W and Tube Deck Mounted (TX T101)
No Image Steel Tube (B)    3 Deck  No Yes No No In Review
SBB03a
Side-Mounted Rectangular Tube Bridge Railing
No image. Steel Tube (B)    Unknown  No No No No
SBB03c
Nested W-Beam with Tubular Backup Culvert Rail (OH Type 5 w/ Tubular Backup)
No Image Steel Tube (B)  Report 350  3 Deck  No Yes No No In Review
SBB04c
Annisquam River Bridge
No Image Steel Tube (B)  Report 350  3 Parapet  No Yes No No In Review
SBB04d
MN Type 3 Combo Railing
No Image Steel Tube (B)    4 Parapet  No Yes No Yes In Review
SBB06c
TX T4
No Image Steel Tube (B)  Report 350  3 Parapet  No Yes No No In Review
SBB07d
Tacoma Narrows Bridge
No Image Steel Tube (B)  Report 350  4 Parapet  No Yes No No In Review
SBB08c
TL3 Ohio Box Beam
No image. Steel Tube (B)  Report 350  3 Deck  No No No No In Review
SBB10b
IN Steel Tube Bridge Rail PS2
No image. Steel Tube (B)    Unknown  No No No No In Review
SBB16d
CA Type ST-10
No Image Steel Tube (B)  Report 350  4 Parapet  Yes Yes Yes No Not Reviewed
SBB18b
Washington DC Historic Retrofit
No Image Steel Tube (B)    2 Curb/Sidewalk  Yes No Yes No In Review
SBB19d
IL 2399
No Image Steel Tube (B)    Curb/Sidewalk  No No No No In Review
SBB20d
MI Tubular Railing
No Image Steel Tube (B)    4 Curb/Sidewalk  No Yes No No In Review
SBB21c
MI Open Parapet
No Image Steel Tube (B)    3 Unknown  No No No No In Review
SBB25d
MI Two Tube
No Image Steel Tube (B)    4 Curb/Sidewalk  No Yes No No In Review
SBB26d
NY Two Tube
No Image Steel Tube (B)    4 Curb/Sidewalk  No Yes No No In Review
SBB27d
NY Three Tube
No Image Steel Tube (B)    4 Deck  No Yes No No In Review
SBB28d
NY Four Tube
No Image Steel Tube (B)  Report 350  4 Curb/Sidewalk  No Yes No No In Review
SBB29d
NY Five Tube
No Image Steel Tube (B)  Report 350  4 Curb/Sidewalk  No Yes No Yes In Review
SBB30b
OR Two Tube
No Image Steel Tube (B)    2 Curb/Sidewalk  No Yes No No In Review
SBB31d
OR Two Tube
No Image Steel Tube (B)    4 Side  No Yes No No In Review
SBB32d
OR Three Tube
No Image Steel Tube (B)    4 Curb/Sidewalk  No Yes No No In Review
SBB34e
TX TYpe C202
No image. Steel Tube (B)    5 Parapet  No Yes No No In Review
SBB35b
TX Energy Absorbing Bridge Railing
No image. Steel Tube (B)    2 Deck  No Yes No No In Review
SBB36c
WY Two Tube
No Image Steel Tube (B)    3 Curb/Sidewalk  No Yes No No In Review
SBB36d
WY Two Tube
No Image Steel Tube (B)    4 Curb/Sidewalk  No Yes No No In Review
SBB38d
NETC Two Rail
No image. Steel Tube (B)    4 Curb/Sidewalk  No Yes No No In Review
SBB39d
Illinois Side Mounted Steel Railing
No image. Unknown    4 Side  No No No No In Review
SBB40c
TXDOT T77
No Image Steel Tube (B)  Report 350  3 Curb/Sidewalk  Yes Yes No Yes In Review
SBB41d
California Type 90 Concrete/Steel Bridge Railing
No Image Steel Tube (B)  Report 350  4 Parapet  Yes Yes Yes No Not Reviewed
SBB42d
CA Type ST-20
No Image Steel Tube (B)  Report 350  4 Parapet  Yes Yes Yes No Not Reviewed
SBB43d
CA Type ST-30
No Image Steel Tube (B)  Report 350  4 Parapet  Yes Yes No No Not Reviewed
SBB44d
CA Type ST-40 (NETC 4-Bar)
No Image Steel Tube (B)  Report 350  4 Deck  Yes Yes No Yes Not Reviewed
SBB45d
Maine 36" 3-Tube Bridge Railing
No image. Steel Tube (B)  Report 350  4 Curb/Sidewalk  Yes Yes No No Not Reviewed
SBB46d
Modified NETC 4-Bar for Through-Truss Bridges
No Image Steel Tube (B)  Report 350  4 Steel Floor Beam  No Yes Yes No In Review
SBC01a
Vertical Concrete Wall
No Image Cast-in-Place Concrete (C)  AASHTO Guide Spec for Bridge Railings  3 Deck  No No No No In Review
SBC01b
Vertical Concrete Wall
No Image Cast-in-Place Concrete (C)  AASHTO Guide Spec for Bridge Railings  3 Deck  No No No No In Review
SBC01c
TL-3 Vertical Concrete Wall
No Image Cast-in-Place Concrete (C)  AASHTO Guide Spec for Bridge Railings  3 Deck  No No No No In Review
SBC02a
Open-Profile Concrete Bridge Railing
No image. Cast-in-Place Concrete (C)    Unknown  No No No No
SBC02b
Open Profile Concrete
No image. Cast-in-Place Concrete (C)  AASHTO Guide Spec for Bridge Railings  2 Deck  No Yes No No In Review
SBC03a
Aesthetic Balustrade Bridge Railing
No image. Cast-in-Place Concrete (C)    Unknown  No No No No
SBC03b
Aesthetic Baulstrade
No image. Steel W-Beam (W)    2 Unknown  Yes Yes No No In Review
SBC04d
TL-4 F Shape
No Image Cast-in-Place Concrete (C)  Report 350  4 Deck  No No No No In Review
SBC04e
TL-5 F Shape
No Image Cast-in-Place Concrete (C)  Report 350  5 Deck  No No No No In Review
SBC05b
Safety-Shape Concrete Bridge Railing
No image. Cast-in-Place Concrete (C)    Unknown  No No No No
SBC05d
TL-4 Safety Shape
No Image Cast-in-Place Concrete (C)  Report 350  4 Deck  No No No No In Review
SBC05e
TL-5 Safety Shape
No Image Cast-in-Place Concrete (C)  Report 350  5 Parapet  No No No No In Review
SBC07b
TX T411
No Image Cast-in-Place Concrete (C)  Report 350  3 Parapet  Yes Yes No No In Review
SBC07c
Natchez Trace Bridge Rail
No Image Cast-in-Place Concrete (C)  Report 350  3 Parapet  Yes Yes No No Review Complete
SBC07d
TX F411
No Image Cast-in-Place Concrete (C)  Report 350  4 Deck  Yes Yes No No In Review
SBC08d
GA One-Pipe Combo Rail
No Image Cast-in-Place Concrete (C)    4 Parapet  No Yes No Yes In Review
SBC09b
GA Two-Pipe Combo Rail
No Image Cast-in-Place Concrete (C)    2 Parapet  No Yes No Yes In Review
SBC12b
CA Type 80 SW
No Image Cast-in-Place Concrete (C)  Report 350  2 Parapet  Yes Yes No Yes Review Complete
SBC12d
CA Type 80
No Image Cast-in-Place Concrete (C)  Report 350  4 Parapet  No Yes No No Review Complete
SBC13d
CA Type 732
No Image Cast-in-Place Concrete (C)  Report 350  4 Parapet  No No Yes No Not Reviewed
SBC15d
Vertical Wall with Sidewalk
No Image Cast-in-Place Concrete (C)    4 Parapet  No No No No In Review
SBC17b
Precast Clamp Crete Parapet
No image. Precast Concrete (C)  AASHTO Guide Spec for Bridge Railings  4 Deck  No No No No In Review
SBC18b
Precast Clamp Crete
No image. Precast Concrete (C)  AASHTO Guide Spec for Bridge Railings  Deck  No No No No In Review
SBC21d
Safety Shape with Combo Rail
No Image Cast-in-Place Concrete (C)    4 Deck  No Yes No Yes In Review
SBC24b
IA Retrofit Concrete
No Image Cast-in-Place Concrete (C)  AASHTO Guide Spec for Bridge Railings  2 Parapet  No No Yes No In Review
SBC30e
NDOR Aesthetic Concrete Bridge Railing
No Image Cast-in-Place Concrete (C)  Report 350  5 Unknown  Yes No No No In Review
SBC32d
MI Type 5
No Image Unknown    4 Unknown  No No No No In Review
SBC33d
MN Type F with Bicycle Rail
No Image Cast-in-Place Concrete (C)  Report 350  4 Deck  No Yes No Yes In Review
SBC34b
NE Concrete Beam
No Image Cast-in-Place Concrete (C)  AASHTO Guide Spec for Bridge Railings  2 Parapet  No Yes No No In Review
SBC35b
NE Concrete Beam
No Image Cast-in-Place Concrete (C)    2 Parapet  No Yes No No In Review
SBC37b
Precast Bolt-Down Safety Shape
No image. Cast-in-Place Concrete (C)    4 Deck  No No No No In Review
SBC39c
NV Safety Shape Parapet
No Image Cast-in-Place Concrete (C)    3 Parapet  No No No No In Review
SBC40b
OK TR1
No Image Cast-in-Place Concrete (C)    2 Parapet  No Yes No No In Review
SBC41d
OR Vertical Parapet
No Image Cast-in-Place Concrete (C)    4 Parapet  No Yes No No In Review
SBC42d
OR Parapet and Sidewalk
No Image Cast-in-Place Concrete (C)    4 Parapet  No Yes No No In Review
SBC43b
TX C411
No Image Cast-in-Place Concrete (C)    2 Parapet  No Yes No No In Review
SBC44e
TX Type HT
No Image Cast-in-Place Concrete (C)    5 Deck  No Yes No No In Review
SBC47d
TX T501 SW
No Image Cast-in-Place Concrete (C)    4 Parapet  No No No No In Review
SBC47f
TX T501
No Image Cast-in-Place Concrete (C)    6 Deck  No No No No In Review
SBC48f
TX TT
No Image Unknown    6 Unknown  No No No No In Review
SBC52d
FL 42\" Vertical Wall
No Image Unknown    4 Unknown  No No No No In Review
SBC53b
Low-Profile Concrete Bridge Railing
No Image Cast-in-Place Concrete (C)  Report 350  2 Deck  Yes Yes No No Review Complete
SBC54c
Vertical-Face PCB for Composite Decks
No Image Precast Concrete (C)  MASH  3 Deck  No No Yes No Review Complete
SBC55c
TL3 NC Vertical Wall
No Image Cast-in-Place Concrete (C)  AASHTO Guide Spec for Bridge Railings  3 Deck  No No No No Review Complete
SBC55d
TL4 NC Vertical Wall
No Image Cast-in-Place Concrete (C)  AASHTO Guide Spec for Bridge Railings  4 Deck  No No No No Review Complete
SBC60d
Visi-Barrier 32-inch New Jersey Bridge Railing
No Image Precast Concrete (C)  Report 350  4 Deck  No No Yes No Review Complete
SBC60e
Visi-Barrier 42-inch New Jersey Bridge Railing
No Image Precast Concrete (C)  Report 350  5 Deck  No No Yes No Review Complete
SBC61d
Visi-Barrier 32-in F Bridge Railing
No Image Precast Concrete (C)  Report 350  4 Deck  No No Yes No Review Complete
SBC61e
Visi-Barrier 42-inch F Bridge Railing
No Image Precast Concrete (C)  Report 350  5 Deck  No No Yes No Review Complete
SBC62d
Visi-Barrier 32-inch Single-Slope Bridge Railing
No Image Precast Concrete (C)  Report 350  4 Deck  No No Yes No Review Complete
SBC62e
Visi-Barrier 42-inch Single-Slope Bridge Railing
No Image Precast Concrete (C)  Report 350  5 Deck  No No Yes No Review Complete
SBC63b
California Type 732SW Bridge Railing
No image. Cast-in-Place Concrete (C)  MASH  2 Curb/Sidewalk  No No No Yes Not Reviewed
SBD01a
Curb-Type Timber Bridge Rail
No Image Wood (D)  Report 350  Deck  Yes Yes No No Review Complete
SBD01b
TL-2 Glulam Timber Bridge Railing
No Image Wood (D)  Report 350  2 Deck  Yes Yes No No Review Complete
SBD01d
TL-4 Glulam Timber Bridge Railing
No Image Wood (D)  Report 350  4 Deck  Yes Yes No No Review Complete
SBD02c
Tubular Steel-Backed Timber Railing
No Image Wood (D)  Report 350  3 Deck  Yes Yes No No In Review
SBD03b
OK Timber Rail
No image. Wood (D)    2 Deck  No No No No In Review
SBD04a
Glacier Removable Bridge Railing
No Image Wood (D)  Report 350  1 Side  Yes Yes No No In Review
SBD05a
West Virginia TL-1 Timber Curb-Type Bridge Barrier
No image. Wood (D)  MASH  1 Deck  Yes Yes No No Not Reviewed
SBD07a
Glue-Laminated Wood Curb Railing
No Image Wood (D)  Report 350  1 Deck  Yes Yes No No Review Complete
SBO01d
MDS-4
No Image Other Steel (O)  MASH  4 Deck  No No No No Review Complete
SBO01e
MDS-5
No Image Other Steel (O)  MASH  5 Deck  No No No No Review Complete
SBO03b
Baltimore-Washington Parkway Railing
No Image Cast-in-Place Concrete (C)    2 Parapet  Yes No No No In Review
SBT01a
Side-Mounted Thrie-Beam Bridge Railing
No image. Steel Thrie Beam (T)    Unknown  No No No No
SBT02d
Thrie-Beam Rail for Wood Decks
No Image Steel Thrie Beam (T)  Report 350  4 Side  No Yes No No In Review
SBT04d
DL Thrie Beam Retrofit
No image. Steel Thrie Beam (T)    4 Deck  No Yes Yes No In Review
SBT07
MI Thrie Beam
No Image Steel Thrie Beam (T)    3 Deck  No Yes No No In Review
SBT09b
WA 10-Ga Thrie Beam Retrofit
No Image Steel Thrie Beam (T)    2 Curb/Sidewalk  No Yes Yes No In Review
SBT10c
NE Tubular Thrie Beam
No image. Steel Thrie Beam (T)    3 Deck  No Yes No No In Review
SBW01a
Tubular W-Beam Bridge Railing
No image. Steel W-Beam (W)    Unknown  No No No No
SBW01b
Tubular W-Beam (TX Type T6)
No Image Steel W-Beam (W)    2 Deck  No Yes No No In Review
SBW03c
Side-Mounted W-Beam
No Image Steel W-Beam (W)    3 Side  No Yes No No In Review
SBW04c
MGS Bridge Rail
No Image Steel W-Beam (W)  MASH  3 Side  No Yes Yes No Review Complete
SBW06b
WV W-Beam Retrofit
No Image Steel W-Beam (W)    2 Deck  No Yes Yes No In Review
SBW07a
W-Beam on Glulam Timber Deck
No Image Steel W-Beam (W)  Report 350  1 Side  No Yes No No Review Complete
SBW08a
W-Beam with breakaway wood posts
No Image Steel W-Beam (W)  Report 350  1 Side  Yes Yes No No Review Complete
SBW09c
31-inch W-Beam Guardrail on Low-Fill Box Culvert
No image. Steel W-Beam (W)  MASH  3 Box Culvert  No No No No Not Reviewed
1289 visitors have viewed this page since June 24, 2016.
